Gebildet Automotive Relays for Car Truck Motor Boat Car Starter - 12V DC 100 Amp Split Charge Relay Switch with 2 Pin Footprint + 2 Terminal

• 【Continuous Relay】 You can use it as a continuous relay. If the relay operates for 5 hours continuously, it's best to stop it and then use it again. It can handle a continuous current of 50A ~ 60A.
• 【Package Contents】 1 x Heavy-Duty Split Charge On/Off Relay (100A); 2 x Terminals; 2 x Mounting Brackets
• 【High Capacity】 Up to 100A coil capacity, easily handling high-current applications, high-power, or on/off switching.
• 【Long Lifespan】 Electrical life expectancy: 100,000 operations (at 30 operations/min) Mechanical life expectancy: 10,000,000 operations, maintaining high performance during continuous operation.
• 【Applicable】 Heavy-duty automotive relays offer a standard contact form and feature the standard 4-pin layout, suitable for starter kill, supervised dome lights, trunk release, polarity change, door lock, power control, etc.

Interchangeable/Compatible with: All vehicles and devices equipped with a 12-volt DC power source. Coil Specifications: Nominal Voltage (VDC): 12V Coil Resistance (4.8W / 2.4W): 30/60 Max. Operating Voltage (VDC): 6.0 ~ 8.0 Release Voltage (VDC): 1.2 ~ 3.6 Max. Applicable Voltage (VDC): 15.6 Contact Specifications: Contact Material: AgSnO12 Contact Form: Normally Open Contact Ratings: NO: 100A 12VDC Contact Resistance: 100mΩ Max at 6VDC 1A Maximum Switching Current: 300A (5ms) Max. Switching Voltage: 75VDC Max. Switching Power: 2000W
