Youmile 2PCS L298N Motor Drive Controller Board DC Dual H-Bridge Robot Stepper Motor Control and Drives Module for Arduino Smart Car With Dupont Cable

• The signal is shown in the figure
• The connecting method is shown inbelow figure after enable ENA ENB
• Driving DC motor Because the module is drived by double H bridge,it can drive two motors simultaneously.
• Input the following driving timing from IN1-IN4 then the speed and direction of the stepper motor can be controlled
• Package Content: 2 x L298N Motor Drive Controller Board, 1 x 11.8" male-FeMale Dupont Cables 12 PIN, 1 x 19.6" 28AWG Wire

Specification: Chip: L298N Logic voltage: 5V Logic current 0mA-36mA Storage Temperature: -20 ℃ to ℃ to +135 Operating mode: H-bridge driver (dual) Drive voltage: 5V-35V Drive current: 2A (MAX single bridge) Maximum power: 25W Dimensions: 43x43x27mm This module has a built-in 5v power supply, when the driving voltage is 7v-35v, this supply is suitable for power supply DO NOT input voltage to +5v supply interface, however ledding out 5v for external use is available. When ENA enable IN1 IN2 control OUT1 OUT2 When ENB enable IN3 IN4 control OUT3 OUT4 Package Included: 2 x L298N Motor Drive Controller Board 1 x 11.8" male-FeMale Dupont Cables 12 PIN 1 x 19.6" 28AWG Wire
