Generator Automatic Voltage Regulator, Input 170-265V AC Max Output DC 15A/95V GAVR-15A Stabilizer Power Regulator

• High-quality electronic components ensure stable performance.
• The voltage is automatically adjusted to meet your needs.
• The product has low frequency and establishes a circuit when the generator speed drops.
• With of shunt compensation.
• This product is very practical generator accessories.

Specification: Model: GAVR-15A Input power: 170-265V AC 50/60HZ Maximum output: 15A, 95A DC (10seconds) Voltage mediation rate: 0.5% Generator field resistance: Minimum 9 ohms External potentiometer: ¡À8% for 1K ohm 1/2W potentiometer Voltage establishment (initial): The voltage is automatically established when the residual magnetization voltage is greater than 6V 25HZ. Low frequency protection: circuit with output voltage dropping when the number of revolutions of the built-in generator decreases Operating temperature: 40-60 Product dimension: 151mm(L)*106mm(W)*70mm(H) / 5.9*4.2*2.8in Package list: 1 * Generator Voltage Regulator Note: The actual product color may deviate from the photo due to light. There may be a slight deviation in the measurement of product.
