Bosch 0 332 019 150 Relay

• Normally open relay, 12V, relay switch, five pole relay
• Developed to be durable and robust through accurate processing and the use of ideal-quality materials: allows for up to 250 000 switching cycles
• 12V 30A relay: rated switching currents of up to 30 A - For high power
• Temperature resistant design: provides the ability to cope with ambient temperatures reaching from -40 Degree C up to +100 Degree C
• Base plate and housing made from fiber-reinforced polyamide: High corrosion resistance
• Housing: IP5K4, Terminal: IP20

At several applications in vehicles, car relays are required to close or separate electrical circuits. Bosch provides a wide range of automotive relays for the specific requirements of each vehicle model. The comprehensive range consists of micro, mini and power relays. Relays feature two electrically separated circuits. The load circuit allows a high switching capacity which is activated by the control circuit. Reliably perform switching operations in a wide range of vehicles due to its compact design: The Bosch mini relay allows rated switching currents of up to 75 A and has a nominal voltage of either 12 or 24 volts.
