YOFASEN HDMI to SDI Extender - HDMI Extender 1080P Converter HD Video Audio Adapter, Black, 9.5 * 5 * 2.5CM

• Frequency Bandwidth: 225MHz/link (HDMI 1.3).
• Input TMDS Signal: 3.3 volts.
• Coaxial Cable Distance: Full HD up to 100M (RG-6U cables) & HD up to 200M (RG-6U cables) & SD up to 300M (RG-6U cables).
• In/Output Support Resolution: 480p, 576p, 720p@50/59.94,60 & 1080p@23.98/24/25/29.97/30/50/59.94/60.
• The HDMI Over Single Coax Extender supports HDMI 1.3 and HDCP 1.1 with features such as Deep Color and 1080p.

The Extender offers the most convenient solution for HDMI extension over a singlecoaxial cable with long distance capability, and is the perfect solution for any application. Specifications: Frequency Bandwidth:225MHz/link (HDMI 1.3) In/Output Support Resolution: - 480p, 576p, 720p@50/59.94,60 - 1080p@23.98/24/25/29.97/30/50/59.94/60 Input TMDS Signal:3.3 volts Input DDC Signal:5.0 volts/P-P ESD Protection Human body model:±8kV (air-gap discharge) / ±4kV (contact discharge) Bare metal size:9.5*5*2.5cm Weight (g):115 Power Supply:5V1A DC Power consumption:2.3 watts (TX); 2.2 watts (RX) Operation temperature:32~104 °F Storage temperature:-4 ~140 °F Relative humidity:20~90 % RH (no condensation) Features: Flexible extension of high-bandwidth HDMI 1.3 thanks to the performance and reliability of 75Ohm RG-6U Coax cable. Audio and video are transmitted digitally over the 75Ohm RG-6U Coax cable with zero signal loss. Single Link Range: 1080p/60, 12 bit color depth. Compliant with HDMI 1.3, HDCP 1.1 standards. Supports digital video formats in Deep Color Mode at up to 12bits/color. Supports PCM 48KHz audio. Supports Cascade function in Transmitter and Receiver and it is easy to build a network system by installer. Lip-Sync Pass Through. Bi-directional IR system allowing for control of source or display (IR accessories included) Package: 1 * HDMI Extender(TX and RX) 1 * IR Blaster (TX) 1 * IR Receiver (RX) 2 * DC 5V in line power supply 1 * User Manual NOTE: 1. Video signal transfer only, can't improve the video quality. 2. Starting time - around 10 seconds. Thanks for your purchase!
