TRACOPOWER DC/DC Converter for PCB TMR 6-0515 Number of outputs: 1 x 5 V/DC 24 V/DC 250 mA 6 W 1 pc(s)

• TracoPower TMR 6-0515 · Contents: 1 pc(s)
• The product comes in an ultra-compact SIP-8 plastic housing with a small footprint. Excellent efficiency in a wide temperature range from -40 ° to +65 ° C
• The very compact dimensions of the converters make their applications an ideal solution for communication, instrumentation and industrial equipment where space is critical
• Other features: Remote shutdown control and continuous short circuit protection

The tmr-6 Series is a new family of isolated DC-DC converters 6 W modules, regulated output, with wide input voltage ranges. The product is supplied in a plastic box sip-8 ultra-compact with a minimum amount of space An excellent efficiency in a wide temperature range of -40 ° to + 85 °C. The very compact dimensions the converters make application an ideal solution for the communication equipment, instrumentation and or space is critical. Other features: Stop with the control and continuous protection of short circuit. () connection: solder tabs Output Current (Max.) : 250 mA Efficacy (Max.) : 84% Product Height: 15.3 mm Product Width: 21.8 mm Product Length: 9.1 mm Additional Technical Data: Input voltage: 4,5-9,0 V Output Voltage: 24 V Output Current: 250 mA Power: 6 W Efficiency: 84% Line Regulation: 0.2% max., Load Regulation (0-100%) 1.0% max Ripple and noise: <50 mVpk-pk (20 MHz bandwidth) Protection against court-cicuits Temperature range: -40 °C to + 65 ° Approvals: UL/cUL 60950-1, IEC/EN 60950-1 Number of outputs: 1 x Weight: 4.8 g Power: 6 W Operating Temperature (Max.) (num): 65 °C Operating Temperature (Min.) (num): -40 °C Input Voltage (Max.) : 9 V/DC Input Voltage (Min.) : 4.5 V DC Output Voltage: 24 V/DC Rated voltage: 5 V/DC
