TECNOIOT 1pc pressure sensor transmitter DC 5V G1 / 4 1.2 MPa pressure sensor 174 PSI

• 【DC 5V G1 / 4 pressure sensor】 ☆☆☆DC 5V G1 / 4 1.2 MPa 174 PSI Pressure Sensor Transmitter Pressure Transducer For Water Diesel☆☆☆
• 【Feature】➮║Suitable for wall oven, gas oven, gas storage, etc. all kinds of hydraulic and pneumatic pressure measurements║Suitable for batches of products for civil use║Static accuracy: plus or minus 1.0% FS║
• 【High performance】➮║✔ Pressure range 0-1.2 MPa (can be customized according to customer's requirements)║Wide temperature compensation range║Medium for non-corrosive gas, water, oil, etc.║
• 【Specifications-1】 ➮║✔Working voltage: 5.0 VDC║✔Output voltage: 0.5-4.5 VDC║✔Operating current: less than 10mA║✔Working pressure range: 0-1 , 2 MPa║✔ The greatest pressure: 2.4 MPa║✔ Destroy the pressure: 3.0 MPa║
• 【Specifications-2】 ➮║✔ Working TEMP. Range: 0-85 degrees Celsius Storage temperature range: 0-100 degrees Celsius║✔ Measurement error: + -1.5% FSO FS✔ Temperature range error: + -3.5% FSO F Response time: less 2.0 ms m Lifecycle: 500,000 parts║

DC 5V G1/4 Pressure Sensor Transmitter Pressure Transducer 1.2 MPa 174 PSI for Water Gas Oil Characteristic: Suitable for wall hanging furnace, gas furnace, gas storage, etc all kinds of hydraulic, pneumatic pressure measurement Suitable for civil use product batch Static accuracy: plus or minus 1.0% FS Pressure range 0-1.2 MPa (can be customized according to customer requirements) Wide range of temperature compensation Medium for non-corrosive gas, water, oil, etc Specifications: Working Voltage: 5.0 VDC Output Voltage: 0.5-4.5 VDC Working Current: <=10 mA Working Pressure Range: 0-1.2 MPa The Biggest Pressure: 2.4 MPa Destroy Pressure: 3.0 MPa Working TEMP. Range: 0-85 Celsius Degree Storage Temperature Range: 0-100 Celsius Degree Measuring Error: +_ 1.5 %FSO Temperature Range Error: +_3.5 %FSO Response Time: <=2.0 ms Cycle Life: 500,000 pcs Packet Contains: 1pc x DC 5V G1/4 Pressure Sensor Transmitter Pressure Transducer 1.2 MPa 174 PSI
