TB6600 Stepper Motor Driver CNC Controller 0.2-5A DC12-48V Hybrid Two-Phase for CNC Machine Tools

• Good Perfoemance: The driver adopts the current loop subdivision control of the driver, the motor torsion ripple is small, the low speed is very stable, and there is almost no vibration and noise.
• High-Spped Torsion And High Positioning Accuracy: High-speed torsion is much higher than other two-phase drives, high positioning accuracy
• Two-Phase Stepper Motor Driver: Average current control, two-phase sinusoidal current drive output and opto-isolated input/output
• Detailed Parameter: The two-phase hybrid stepping motor has a dynamic voltage of 12 to 48 V, a current of less than 5 A, and an outer diameter of 35 to 86 mm.
• Wide Application: Widely used in engraving machines, CNC machine tools, packaging machinery, etc.

Specification: Item Type: Input Voltage: DC 12-48V Input Input: 1-5A Current, Select Drive Stepper Motor Output Current: 0.2A-5A Temperature Operating Temperature: -10-45℃; Storage Temperature -40℃ -70℃ Humidity: No Condensation, No Drop Gas prohibits combustible gas and conductive dust Set the Number of Steps Per Motor Step for the Motor 200(synchronizing), 400 (2 segments), 1600 (8 segments), and 3200 Steps (16 segments). Power Interface: 1. DC +, DC-: Connect the drive power DC +: DC Power Supply Level, Power Supply Voltage Dc 12 To 48v, Maximum Current 5a DC-: DC Power Supply Negative Level. 2. A + A-B + B-: Connecting Two-Phase Hybrid Stepping Motor The connection between the driver and the two-phase hybrid stepping motor and the four-wire system, the parallel and series connection of the motor windings, and the connection method, the high-speed performance is high, but the driving current is large (the motor winding current is 1.73 times), when the driving current is equal series connection when the motor winding current Troubleshooting: State Light Indication RUN: The Green Light Works Normally. ERR: Red Light, Power, Indicator Light, Power Indicator Control Definition: PUL +: stepping pulse input side or positive pulse input positive terminal PUL-: Negative input of negative input pulse or positive pulse signal DIR +: input the positive direction step direction or input positive terminal negative pulse signal DIR-: Negative terminal for step direction input or reverse pulse input in negative direction EN +: Offline can reset the input EN-: Offline resettable input negative Package List: 1 x TB6600 Stepper Motor Driver
