Sandvik Coromant R210-090412M-PM4230 CoroMill 210 insert for milling (Pack of 10)

• Benefits of this product family: High table feed due to the chip thinning effect – high productivity
• First choice face milling cutter in long overhang machining
• Multipurpose tool. Face milling, boring possibilities, ramping and plunge milling

Part of the CoroMill 210 product family. The CoroMill 210 is a very productive roughing concept to use when high metal removal rate is the first priority. A 10° entering angle allows extreme feed rates when face milling. This directs the cutting forces in an axial direction which provides a stable cutting action and no vibration tendency. PRODUCT SPECIFICATION: Material classification (TMC1ISO): P (ISO P Steel); Grade: 4230 ; ISO Cutting Tool Material: HC ; Coating Process Type: CVD ; Coating Type: Ti(C,N)+Al2O3+TiN ; Substrate Type: WC ; BS, Wiper Edge Length: 0.77 mm ; BS, Wiper Edge Length: 0.030315 inch ; CBMD, Chip Breaker Manufacturer'S Designation: PM ; CTPT, Operation Type: Medium ; CUTINT_SIZESHAPE, Insert Size And Shape: CoroMill 210 -0904 s=4 ; HAND, Hand: R ; IC, Inscribed Circle Diameter: 9.4 mm ; IC, Inscribed Circle Diameter: 0.370079 inch ; KRINS, Major Cutting Edge Angle: 10 deg ; LE, Cutting Edge Effective Length: 6.2 mm ; LE, Cutting Edge Effective Length: 0.244094 inch ; RE, Corner Radius: 1 mm ; RE, Corner Radius: 0.03937 inch ; REEQ, Corner Radius Equivalent: 2.5 mm ; REEQ, Corner Radius Equivalent: 0.098425 inch ; S, Insert Thickness: 4 mm ; S, Insert Thickness: 0.15748 inch ; SC, Insert Shape Code: S ; WT, Weight Of Item: 0.0035 kg ; WT, Weight Of Item: 0.0077 lbs ;
