Pxyelec Platform Scale Weighting Load Cell Sensor for Electronic Balance 50 KG

• Load cell material: Aluminium, stable and stable, and has a long service life
• Application: Weight sensor 4 leads, easy to use, plus 10-15V drive voltage, direct output as a voltage signal due to force changes. For price computing scales; platform scales; platform balance; for DIY Arduino etc
• Specification: Rated output: 2.0 ±0.15 mV/V, Accuracy class: C2; Input resistance (Ω): 402 ±6, Output resistance (Ω): 350 ±3; Method of connecting wire: (Red: Power+) (Black: Power-) (Green: Signal+) (White: Signal-)
• Good performance: Electronic load cell has high precision, small comprehensive error and stable and durable performance
• Package included: 1 pcs weighting sensor. Capacity (kg): 50 kg

Application: Price computing scales Capacity (kg): 50kg Rated output: 2.0±0.15 mV/V Accuracy class: C2 Maximum number of verification intervals (nMax): 2000 Minmum Load cell verification intervals (vMin): Emax/5000 Combined erro (%RO): ≤±0.03 Creep (%RO/30min): 0.03 Temperature effect on sensitivity (%RO/°C): 0.0016 Temperature effect on zero (%RO/°C): 0.003 Zero balance (%RO): ±1.0 Input resistance (Ω): 402±6 Output resistance (Ω): 350±3 Insulation resistance (MΩ)(50V): 5000 Recommended excitation voltage (V): 10~15 Compensated temperature range (°C): -10~+40 Operating temperature range (°C): -35~+80 Sate overload (%RO): 150 Ultimate overload (%RO): 200 Load cell material: Aluminium Plafform size:350x350mm Method of connecting wire: (Red: Power+)(Black: Power-)(Green: Signal+)(White: Signal-) Package included: 1pcs Weighting Sensor
