Mut 703000695 Group Anti-Condensation for Biomass

• Anti-fog Group Model blumut 78 °C (Ric.72 °C) vs 1 1/4
• Model blumut 78 °C
• For heating installations
• Calibration at 78 °C
• Built-in ball valve G1 1/4 bocchettoni attacci tapping

It is a complete Thermostatic Group of condensate pump, used to connect a solid fuel boiler (pallet, wood, smoking chips.) With one or more thermal accumulators inerziali. is an extremely simple and functional device, very compact and easy to install. The main feature is to work the boiler always at the highest possible temperature in order to prevent the formation of condensation acid and laminated to ensure a loading of the tank of accumulation without Mix The Water Inside. The group is also a thermal Anti Shock System and allows you to take advantage of the maximum efficiency of the boiler with a consequent energy saving. Easily replaceable opening Thermostatic Elements used have different temperatures ranging from 50 to 87 °C, in order to adapt easily operating temperature to the different characteristics of the installation. Also has the possibility of promoting the natural movement between boiler and accumulation with the pump stops. Very Important As function in case of lack of electricity is guaranteed a minimum water flow cooling of the boiler. To comply with the essential requirements of low voltage directives: 73/23/EEC and EMC S.M.I. – 2014/30/EU electromagnetic compatibility – ErP 2009/125/EU – Ped 2014/68/EU Art. 4.3 Technical Data: Pressure: PN Class 6 (up to PN10 second recirculating) prevalence Max pump [M]: 6.2 m (water pump Standard installed) fluid/water with max: 50% Glycol Temp. Max water max thermal: (T. amb. Max 110 °C to 50 °C) Power Max System (DT = 20 °C): ∆ P = 0 kPa = > kW 79; P = 15 Kpa = > kW 65 rated voltage: 230 V AC, 50/60 Hz Power consumption: 3 ÷ 45 W of movement: Yonos para RS Pump 25/6 – 130 RKA FS3 F14 capable of Protection: IP x4D pump power consumption: (1 – 230 V pump) 0.03 ÷ 0.44 A Pump Class: F – TF110 materials: Body: gg25 cast iron (gjl-250 – uni en 1561) ball valves in spray Brass CW 617 N (Uni en 12165) insulation shell: High Density EPP (45 kg/m3) Special indoor: CW 614 N Brass (Uni en 12164): AVP Chrome Caps.
