Manhattan HDMI Coupler - 4K, Female to Female, 10.2 Gbps, 90° Connection, Polybag

• Connects 2 HDMI cables
• Supports 4K resolution
• 90°, passive coupling connects two cables to overcome distance limitations
• Gold-plated contacts for better performance
• Intended for use with Manhattan HDMI cables

Description • Connects 2 HDMI cables • Supports 4K resolution • 90°, passive coupling connects 2 cables to overcome distance limitations • Gold-plated contacts for better performance • Intended for use with Manhattan HDMI cables Easily connect two HDMI cables to work over higher distances. The Manhattan HDMI adapter is ideal for joining two HDMI cables to give additional length to a cable, passively. This HDMI coupler allows 4K resolution and a bandwidth of 10.2 Gbps at 340 MHz. Specifications Standards and Certifications • RoHS2 • ISO 9002 General: • Bandwidth: 10.2 Gbps • 340 MHz • Meets or exceeds existing HDMI standards • Length: 3 cm (1.1 Inch) Connectors • HDMI A female, 19-pin gold-plated • HDMI A female, 19-pin gold-plated Electrical • Current rating: 0.5 ADC • Withstanding voltage: 300 VDC • Insulation resistance: 5 MOhm • Conductive resistance: 2 Ohm General • Length (overall): 30 x 20 x 21.5 mm (1.2 x 0.8 x 0.9 Inch) • Weight: 10 g (0.35 oz) • Moulded PVC Package Contents • HDMI Adapter, A to A
