Pressure Transducer 0~50 BAR, IP65 Analog High Accuracy Water Pressure Sensor
About this item
- The outer shell of the product is made of stainless steel, and is equipped with advanced ceramic and customized process chip.
- The product has high precision, small size, light weight and easy installation and use.
- Stable product performance, small long-term drift and long life.
- The product has passed EMC and is more stable.
- level: IP65; input voltage: 5±0.25VDC / 5~32VDC; technology: piezoresistive; screw connection: G3/8.
Product description
Specification: Level of IP65 Input Voltage: 5±0.25VDC/5~32VDC Technology: Piezoresistance Screw Connection: G3/8 Output Signal:Analog Signal Measuring Range(Optional):0~2/5/10/20/30/40/50 BAR Output Pattern:Three-wire Overload Pressure:2 Times Full Range Pressure Blasting Pressure:3 Times Full Range Pressure Comprehensive Accuracy (non-linearity + repeatability + hysteresis): ± 1% FS (0 ~ 80 ) ± 1.5% FS (-20 ~ 100 ) ± 3% FS (-40 ~ 125 ) Electrical Connection: Fit for Packard Connector (Three-core) Package List: 1*Pressure Sensor Note: 1. As different computers display colors differently, the color of the actual item may vary slightly from the images. 2. Please allow 1-3mm differs due to manual measurement.
Product details
