FOURKAY 1x8 4K@60Hz HDMI Splitter Extender over Cat6/7 Ethernet with 8 PoC receivers. HDMI Loop Out and Audio Extraction on TX. Send 4K up to 35m / 1080p to 60m. Remote Control source from Receivers

• Split and distribute 1 HDMI input signal to 8 remote displays via Cat6/7 Ethernet cables and one local display via the loop through HDMI output port on the transmitter unit.
• Distribute content for distances up to 35 meters at resolution of 4K2K@60Hz or 60 meters at 1080P@60Hz via CAT6/7 cables. Enable DSC compression mode to extend 4K distribution range to up to 70m on any ports requiring longer range.
• Digital and Analogue audio extraction ports on the transmitter unit enable easy connection of audio to amplifiers and audio mixers.
• The PoC Receivers are powered from the transmitter unit so only one power supply unit is required at the transmitter unit - no power socket required at the receiver end. Power supply is included.
• Supports one way Infra Red remote control of the TV source device from any of the receivers. IR receiver and Blaster cables are included.

This high quality HDMI 1x8 Splitter can distribute 1 HDMI source signal (eg Sky box, games console, PC, Fire stick) to any 8 remote display devices via CAT receivers plus one local device via the HDMI loop out port on the transmitter. UHD / 4K2K@60Hz video can be transmitted to a distance of 35 meters via Cat6/7 cable. 4K2K@30Hz can be distributed up to 50 meters and 1080p @60Hz can be transmitted over a distance of up to 60 meters. The CAT HDMI receivers are powered by the transmitter over the Ethernet cable so installation is straightforward with no extra power sockets required at the display end. The integrated analogue or optical audio extraction feature of this device is extremely useful where connections to amplifiers or other audio equipment is required. Infra Red remote control of the HDMI source is possible from in front of any of the display devices using the included IR cables. - Allows 1 HDMI audio/video source to be distributed to up to 9 display devices – 8 over Ethernet and one by HDMI lead. - HDMI 2.0b, HDCP 2.2 and HDCP 1.x compliant. - Supports 594MHz/18Gbps video bandwidth and video resolution up to 4K2K@50/60Hz 4:4:4 - Colour Depth : 8-bit,10-bit,12-bit(1080p@60Hz) ; 8-bit (4K2K@60Hz YUV4:4:4) ; 8-bit,10-bit,12-bit(4K2K@60Hz YCbCr 4:2:2/4:2:0) - Colour Space : RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0 - Supports HDR, HDR10+, HLG and Dolby vision. - HDMI Audio Formats: LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X. - Coaxial Audio Formats: PCM2.0, Dolby Digital / Plus, DTS 2.0/5.1 - Analogue Audio Formats: PCM 2.0CH - Supports one-way IR control signal pass-through. - Transmitter Dimensions: 300mm (W) × 100mm (D) × 28mm (H) Weight 823g - Receiver Dimensions: 88mm (W) × 61mm (D) × 18mm (H) Weight 155g
