Electronic 24V~380V Pressure Control Switch Air Compressor Pressure Controller for Refrigeration Equipment or Automatic System Air Conditioning Equipment

• Material: Made of high quality material, anti-corrosion, durable in use. Micro switch life: 100,000 times
• Suitable Media: Apply for freon, air, liquid and other non-corrosive media. Power supply voltage: 24V~380V.
• Reasonable Design: Equipped with mounting bracket and screws, easy to install. The SPDT switch ensures contact switching.
• Pressure Regulating range (bar): -1 (Min) ~0 (Max). Differential pressure adjustment range (bar): 0.2 (Min) ~0.5 (Max). Maximum air tightness test (bar): 16.5
• Scope of Application: Mainly used for high and low voltage limit control of refrigeration equipment or automatic system air conditioning equipment.

Specification: Material: Plastic, iron plating nickel, stainless steel, brass Weight: 396g/14oz Pressure regulating range (bar): -1 (Min) ~0 (Max) Differential pressure adjustment range (bar): 0.2 (Min) ~0.5 (Max) Factory setting (bar): -0.2 (OFF/ON) ~ -0.6 (ON/OFF) Maximum air tightness test (bar): 16.5 Power supply voltage: 24V~380V Micro switch life: 100,000 times Electrical parameters: When the voltage is 125VAC, the non-inductive current is 20A, the full load current is 15A, and the instantaneous current is 72A. When the voltage is 250VAC, the non-inductive current is 10A, the full load current is 8A, and the instantaneous current is 72A. Package List: 1* Pressure Control Switch 1* Mounting Bracket 4* Screw
