DollaTek DSO150 Digital Shell Oscilloscope 2.4" TFT 1Msps DIY Housing Probe Kit Electronic Training DIY kit

• This item is made by improved circuit, circuit board, mechanical structure and operation mode based on DSO138 oscilloscope.
• With automatic, regular and one-shot mode, easy to capture the moment waveform, can be triggered by rising or falling edge.
• Digital display waveform parameters, can be displayed parameters: frequency, period, pulse width, duty cycle, maximum, minimum, average, RMS.
• Adjustable trigger level position with instructions, observable previous trigger waveform (negative delay).
• HOLD function, can freeze waveform display at any time. Save / recall waveform, waveform does not disappear when turning off.

DollaTek DSO150 Digital Shell Oscilloscope 2.4" TFT 1Msps DIY Housing Probe Kit Electronic Training DIY kit (SMD not soldered) Features: This item is made by improved circuit, circuit board, mechanical structure and operation mode based on DSO138 oscilloscope. With automatic, regular and one-shot mode, easy to capture the moment waveform, can be triggered by rising or falling edge. Digital display waveform parameters, can be displayed parameters: frequency, period, pulse width, duty cycle, maximum, minimum, average, RMS. Adjustable trigger level position with instructions, observable previous trigger waveform (negative delay). HOLD function, can freeze waveform display at any time. Save / recall waveform, waveform does not disappear when turning off. Specifications: Processor: ARM Cortex-M3 STM32F103C8 2.4" TFT screen with 320 x 240 resolution Supply voltage: DC 9V(8V - 10V acceptable) Maximum real-time sampling rate: 1Msps Accuracy: 12bit Sampling buffer depth: 1024 Bytes Analog bandwidth: 0 - 200KHz Vertical Sensitivity: 5mV / Div - 20V / Div(1-2-5 grade progressive manner) Adjustable vertical displacement with instructions Input impedance: 1M¦¸ Maximum input voltage: 50Vpp (1: 1 probe), 400Vpp (10: 1 probe) Coupling modes: DC / AC / GND Comes with 1Hz /3.3V square wave test signal source. The horizontal time base range: 10¦Ìs / Div - 50¦Ìs / Div (1-2-5 grade progressive manner) Dimension: 115 x 75 x 22mm Package includes: 1 x DSO150 oscilloscope DIY kit
