AITRIP 2pcs, DC 400W 15A Power Supply LED Drive,Boost Module, DC-DC Step-up Converter Board 400W Boost Converter Power Inverter Module 8-50V to 10-60V for Electric Equipment and Digital Products

• This is a great 400W DC to DC step-up power supply module for electric equipment, digital products, laptop, etc.
• DC 8.5V to 50V input voltage, 10V to 60V continuously adjustable output voltage, 15A maximum input current, 12A maximum output current
• High efficiency, the maximum conversion efficiency can be 96% and efficiency is related to input/output voltage, current and voltage difference.
• widely used for electric equipment, digital products, laptop and more. It can also be used as a driver for high power LED lights or voltage regulator for solar panels
• Input and output are designed with screw terminals for convenient wire connection and disconnection.

400W 15A : DC 400W 15A Step-up Boost Converter Constant Current Power Supply 8.5-50V to 10-60V Module name :400W boost constant current module; Module properties: non-isolated step-up module (BOOST); Input voltage: DC8.5V-50V; Input current: 15A (MAX) exceeds 8A please enhance heat dissipation. High performance: Output voltage: 10-60V continuously adjustable; Constant range: 0.2-12A;Operating frequency: 150KHz;Conversion efficiency: up to 96%; Overcurrent protection: yes; Input reverse polarity protection: no. WIDE APPLICATION: widely used for electric equipment, digital products, laptop and more. It can also be used as a driver for high power LED lights or voltage regulator for solar panels Specifications: Type: Non-isolated boost module Input Voltage: DC8.5V to 50V Output Voltage: DC10V to 60V (continuously adjustable, default 19V) Max. Input Current: 15A (please enhance heat dissipation if more than 8A) Max. Output Current: 12A (related to the input and output voltage difference, the greater voltage difference is, the smaller output current will be. please enhance heat dissipation when current is over 7A) Quiescent Current: 10mA(will increase when convert 12V to 20V) Constant Current Range: 0.2A to 12A Output Power = Input Voltage*Current Operating Temperature: -40° to 85°(if temperature is too high, please enhance heat dissipation) Input and output are designed with screw terminals for convenient wire connection and disconnection. Package Includes: 2 x Boost Module
