5pcs VL6180 VL6180X Range Finder Optical Ranging Time-of-Flight Distance Senor

X5pcs VL6180 VL6180X Range Finder Optical Ranging Time-of-Flight ToF Distance Sensor Module 3.3V 5V Gesture RecognitionThe VL6180x three-in-one optoelectronic module integrates an IR VSEL (vertical-cavity surface-emitting laser) infrared vertical cavity surface emitting laser source, proximity sensor, and ambient light sensor (ALS). The VL6180X module implements a proximity sensor using the time-of-flight (ToF) measurement principle; the VL6180X includes a SPAD (Single Photon Avalanche Diode) detector array that detects the time at which a single photon is transmitted from the target to the target and back to the module, calculated in conjunction with the signal amplitude. The actual distance, independent of the reflectivity of the object, this actual distance measurement capability can also produce simple but reliable one-dimensional gesture control. The ambient light sensor also has high sensitivity and precision under ultra-low light, wide sensing dynamic range, and ambient light (Lux) corrected output. All components used to support proximity sensors and ambient light sensors are integrated into one packaged optical module. Infrared laser wavelength: 850nmCommunication interface: IIC (400kHz), address 0x29 (7-bit), two programmable GPIORange (near) range: 0 to 100mm Error 13mm Under certain external environmental conditions, such as 100mm in dark environmentsTemperature drift: 9 ~ 15mm Voltage drift: 3 ~ 5mmConversion time: 15msAmbient light range: 1~100kLux 16-bit outputAmbient light gain range: 1 to 40 (eight)Ambient light sensitivity: 0.36 Lux/count (535 nm LED @ 1 kLux.Measured @ gain 20)Angle response: 42 degreesLinearity error: 5% (1 to 300 Lux), 10% (300 to 7500 Lux)Gain error: 1% (gain 20), 7% (gain 1 to 10)Packet Contains:5pcs VL6180X Optical Ranging Sensor Module
