4K HDMI EDID Manager, 10M Output Distance HDMI EDID Feeader Emulator with 16 EDID Modes Support CEC

• One channel HDMI signal input, one channel HDMI signal output
• 16 kinds of EDID mode, adjust the signal source EDID, compatible with the back-end display device
• Supports up to 4K resolution, allowing you to enjoy ultra high definition quality
• HDMI output distance up to 10M, standard 26AWG, 1.4V HDMI cable
• Easy to install, no extra power required

16 EDID modes: A. 4K 2CH B. 4K 5.1CH C. 4K HD D. 1080P 2CH E. 1080P 5.1CH F. 1080P HD G. 1080P 3D 2CH H. 1080P 3D 5.1CH I. 1080P 3D HD J. 1080i 2CH K. 1080I 5.1CH L. 1080i 5.1CH M. 720P 2CH N. 720P 5.1CH O. 720P HD P. sink EDID Connection and operation: 1. Connect a signal source to the HDMI input of the EDID via the HDMI cable. 2. Connect to an input device (such as a TV, etc.) via an HDMI cable. 3. Manually adjust the EDID Manager 16 modes according to the resolution supported by the backend display device. Specification: Product Name: EDID Manager Model: HDSW0006M1 HDMI input audio format: LPCM2.0/DTS/Dolby-AC3 HDMI output cable length: ≤10m, 1.4V 26AWG Maximum operating current: 300mA/5V DC Operating temperature range: 0 to +40°C Storage temperature range: -10 to +55 ° C Size: approx. 5.2 * 4.8 * 2 / 2.0 * 1.9 * 0.8in Weight: approx. 81g Package List: 1 * EDID Manager
