Youmile 20PACK Micro Switch Roller Lever Arm 3Pin AC 5A 125 250V SPDT 1NO 1NC Momentary PCB Terminals Close/Open Switch

• 【Type】 10pcs KW12-3 Micro Limit Switch, Designed to control the movement of a mechanical part.
• 【Contact Material】Copper, Terminal: 3Pin, Rated Voltage: AC 125V-250V, Rated Current: 5A, Action Type: Momentary.
• 【Micro Switch】Covered with a plastic shell and external drive rod, is a contact mechanism with micro contact interval and quick action mechanism, for switching action by a specified stroke and force.
• 【Feature:】Compact size, small contact spacing, short stroke action, bigger torque, small pressing force, quick connect or disconnect, high precision mechanism design offering acute operation and long service life.
• 【Application】Be widely used in computer mouse, automobile electronic products, communications equipment, test instrument, small home appliance, microwave oven, electric rice cooker, medical equipment, building automation, electric tools, etc.

Description: Type: Micro Limit Switch Model: KW12-3 Color: Black, Red, Silver Tone Contact Material: Copper Terminal: 3Pin Rated Voltage: AC 125V-250V Rated Current: 5A Action Type: Momentary Actuator Type: Stainless Steel Roller Lever Working principle: 1.By external mechanical force transmission elements (by pins, buttons, levers, rollers, etc.) will be used to force action on a reed, 2.Producing reed instantaneous action when action shifted to the critical point, 3.so moving contact with the fixed contact spring at the end of the action point fast on or off. 4. When the force is removed on the drive components, 5.Action reed produce reverse action force transmission element reverse stroke 6.The action reaches a critical point reed, instantaneous reverse action. Package included: 20 x Micro Switches Roller Lever Arm 3Pin AC 5A 125 250V
