Xnuiasqe StackChan Kawaii Open-Source AI Desktop Robot CoreS3 Main Controller - SoC

• StackChan is a super kawaii AI desktop robot. It uses the flagship IoT development kit CoreS3 as its main controller, powered by an - SoC featuring a 240 MHz dual-core processor, with 16MB Flash and 8MB PSRAM onboard, and supporting Wi-Fi and BLE.
• Robot body, connected to the main unit, includes a USB-C interface for power and data, a 700 mAh battery, two feedback servos (360-degree continuous rotation on the horizontal and 90-degree movement on the vertical ), two rows totaling 12 RGB LEDs, infrared transmitter and receiver, a three-zone touch panel, and a full-featured NFC module.
• The factory firmware comes with rich features, including vivid and cute expressions and , the XiaoZhi AI agent, as well as support for iOS app video calls, remote avatars, and discovering other nearby StackChan devices.
• The main unit also integrates a 2.0-inch capacitive touch display with a high-strength glass cover, a 0.3 MP camera, a proximity sensor, a 9- IMU (accelerometer + gyroscope + magnetometer), a TF card slot, a 1W speaker, dual microphones, and power/reset buttons.
• The product also supports programming via and UiFlow2, making it easy to implement a wide range of custom functionalities.

Xnuiasqe NOTE: Do not forcibly rotate any movable parts connected to the motors by hand when you are unsure whether the motors are powered and under control, as this may cause hardware damage. Features Based on the CoreS3 main unit For detailed information, please refer to the CoreS3 page Robot body USB-C interface for power and data 700 mAh battery Two feedback servos (360-degree continuous rotation on the horizontal and 90-degree movement on the vertical ) Two rows totaling 12 RGB LEDs Infrared transmitter and receiver Top-mounted three-zone touch panel Full-featured NFC Development platforms UiFlow2 IDE PlatformIO ESP-IDF Applications Desktop companion AI agent Voice-based question and answer Smart home IoT control Color: Gray Material: plastic Package Contents: 1 * Desktop Robot Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
