WITMOTION WT53R-485 laser distance sensor, 4CM-4M measuring counter with alarm function, ± 20mm accuracy, 5-36V UART, waterproof digital measuring tool range finder

• [High performance] Solid-state data output: Selectable measurement range. Embedded system with built-in voltage stabilization circuit in module, pin level compatible with operating voltage 3.3V ~ 5V, 3.3V
• [Robust design] Supports serial port mode and Modbus mode.The two-layer PCB board process is thinner, smaller and more reliable. The metal shield is antistatic. The module is set to long-range mode (maximum measurement distance is 2 meters) by default, but you can change it to high-speed mode if you need high-speed measurements.
• [Strength of WITMOTION] A professional posture measurement solution provider for 8 years. The WITMOTION sensor integrates a uniquely developed dynamic fusion algorithm and Kalman filtering to ensure stable data output, excellent bias stability, low noise level, and improved measurement accuracy.
• [Safety support] 12 months quality guarantee. Option 1. The tutorial link is printed on the guide card in the package. Option 2. Complete tutorial download link: (http://www.youtube.com/c/WITMOTION). Option 3. If you have any questions, please feel free to contact us. We will provide services and solutions that will satisfy our customers. support（at)wit-motion(dot)com
• [Packing list] WT53R-485 module * 1 and Dupont line * 1
