WITMOTION TTL to CAN bus communication serial port to CAN chip converter analyzer transceiver, 14 types of address filtering

• [Robust design] It automatically calculates a large data buffer, 14 groups of address masking filters, and hardware address filtering, and receives only CAN bus data of the specified ID and type. Small, compatible package with various Witte level
• [Plug and play function] USB specification 2.0, CH340 driver compatible
• [Operating system compatibility] Operating system compatibility] Compatible with Windows XP / 7/8/10 32-bit / 64-bit, Linux, Wince, Mac, Vista, etc. CAN baud rate: 3K ~ 1MBps Serial port baud rate: 1200 ~ 921600Bps
• [Safety support] 12 months quality guarantee. Option 1. The tutorial link is printed on the guide card in the package. Option 2. Complete tutorial download link: (https://github.com/WITMOTION/CH340). Option 3. If you have any questions, please feel free to contact us. We will provide services and solutions that will satisfy our customers. support(at)wit-motion(dot)com
• [Packing list] 1x WitMotion USB-CAN serial cable (1 meter) + 1x welcome guide

Link to Tutorial https://wiki.wit-motion.com/english/doku.php?id=communication_module Product description: a. 5V, 3.3V power supply, LDO linear regulator b. CAN baud rate range: 3Kbps--1Mbps c. Serial port baud rate range: 4800bps--460800bps d. Offline self-recovery function e. 14 sets of shielding filters f. The parameters can be set by the AT command, and can be saved even power off. g. data transmission speed: > 600 frames per second h. hardware, software two restore default parameters Module application areas: intelligent buildings, industrial equipment, smart homes and automotive electronics.
