WINGONEER® IIC/I2C/TWI Serial 2004 20x4 LCD Module Shield Blue Blacklight for Arduino UNO MEGA R3

• 2004 LCD display module is a new high-quality 4 line 20 character LCD module.
• Button for contrast adjustment, switch for backlight and IIC communication interface are installed.
• Directly in the Arduino Sensor Shield V5.0 sensor expansion board IIC insert device interface with 4P cable to connect to Arduino Device. The recording and data are displayed directly on the LCD.

WINGONEER IIC/I2C/TWI Serial 2004 20x4 LCD Module Shield Bluelight LCD for Arduino UNO MEGA R3 2004 LCD display module is a new high-quality 4 line 20 character LCD module. Button for contrast adjustment, switch for backlight and IIC communication interface are installed. Directly in the Arduino Sensor Shield V5.0 sensor expansion board IIC insert device interface with 4P cable to connect to Arduino Device. The recording and data are displayed directly on the LCD. Technical specifications: 1. Product Name: IIC LCD2004 character LCD display 2. Operating Voltage: DC 5V 3. Contrast adjustment: Poti 4. Backlight Control: control program or jumper 5. Interface definition: +, -, SDA, SCL 6. Module size: 98 x 60 x 21 mm 7. Unit weight: 78 g 8. Built-in diameter: 3.5 mm 9. horizontal mounting hole center distance: 93mm 10. Vertical mounting hole spacing: 55 mm 11 Screen Size: 98 x 40 x 9.8 mm 12. Operating temperature: -30 ~ + 60°C Package include: 1x 2004 LCD Module
