Wago 221-412 Connection Terminal 2 Wires with Control Lever 0.2-4 mm² Small Transparent Pack of 50

• Connection of all types of conductors even without prior treatment
• Connection of up to 2 conductors
• Easy and tool-free operation thanks to the lever
• Comfortable conductor from 0.14 to 4 mm²
• Packed in a handy resealable cardboard with 50 visolights with full colour printed instructions

Electrical data. Data measured according to IEC/EN 60664-1. Voltage: (II/2): 450 V. Rated shock voltage (II/2): 4 kV. Rated Current: 32A Features: Connection technology: CAGE CLAMP. Handling type: lever Connectable conductor components: copper. Nominal cross section: 4 mm² Single-line conductor: 0.2-4 mm²/24 mm². -12 AWG Stranded Conductor: 0.2 - 4 mm² / 24 - 12 AWG.6 mm² - Thin Cable: 0.14 - 4 mm² / 24 - 12 AWG Maximum stripping length: 11 mm. Total number of clamping points: 2. Total number of potentials: side wiring Wiring. Geometric data. - Width: 13.1 mm. Height: 8.3 mm, Depth: 18.6 mm. Material features: transparent color. Flammability class UL 94: V2. Fire load: 0 MJ Weight: 1.8 g. Outdoor ambient temperature (operation): 85°C Operating temperature: 105°C Conforms to EN 60998: T85. - Packaging type Visolight Pack of 50 poly bags and folding cardboard. - Contents: 50 x Wago connection terminals 221-412. Instruction manual EAN 42 60068446295
