ViD Duo-Crimp no. 300 - 3 in 1 Stripper & Crimping Tool

• Cable type: fine-stranded and solid conductors with PVC insulation
• Application: 0.5 - 6.0mm²
• Inner knife: changeable
• Additional benefits: side cutters, massive up to 4.0mm², flexible up to 6.0mm²; Crimping ferrules of 0.5 - 2.5mm² and 4.0 - 6.0mm²
• Approval / certificate: tested safety TÜV NORD

Wire stripper with crimp function for wire end ferrules 0.5 - 6 mm² Stripping tool with side cutter With the ViD Duo-Crimp No. 300 can be stripped conductor and crimp wire end sleeves. The automatic scanning system does not require adjustment to the cable cross-section. The stripper has an optical length scale of 8 - 20 mm and is suitable for all common flexible and solid conductors between 0.5 mm² - 6.0 mm². The Duo Crimp No. 300 insulated conductor to a length of 5 mm, whereby a splicing of the individual conductors is prevented. The conductor can then be twisted. For pressing wire end ferrules, two pressing ranges of 0.5 - 2.5 mm² and 4.0 - 6.0 mm² are available. A readily accessible side cutter is in the Duo Crimp No. 300, which can be used up to a cable cross-section of 6 mm² (solid conductors up to 4 mm²). APPLICATION - Automatic stripping and crimping of wire end ferrules 0.5 - 6.0 mm² according to DIN 46228-2 PRECISION - Accurate working with automatic stripping prevents damage to the inner conductors ADDITIONAL FUNCTION - Integrated and easily accessible side cutter up to 6.0 mm² QUALITY - 100% Made in Germany - Made of robust and ergonomically shaped glass fiber reinforced polyamide / The durable blades are made of high quality blade steel from Solingen SAFETY - The stripping tool is TÜV / GS tested in terms of safety at work Cable type: fine-stranded and solid conductors with PVC insulation Application: 0.5 - 6.0mm² Inner knife: changeable Additional benefits: side cutters, massive up to 4.0mm², flexible up to 6.0mm²; Crimping ferrules of 0.5 - 2.5mm² and 4.0 - 6.0mm² Approval / certificate: tested safety TÜV NORD Material: glass fiber reinforced polyamide Weight: 115g Length: 160 mm Note: Working with ViD stripping tools is only permitted on potential-free, non-live cables and lines.
