Green-utech USB to TTL 5v UART Serial Dupont Header Cable Wire End USB-TTL-5V-WE for Windws,Linux and Mac OS (5.0V, 6P)

• USB to TTL 5v 6 Pin UART serial cable is connect directly to a microcontroller UART or I/O pins.
• The internal EEPROM descriptors can be programmed in circuit, over USB without any additional voltage requirement. It can be programmed using the FTDI utility software called FT_PROG, which can be downloaded from FTDI Utilities on the FTDI website (www.ftdichip.com).
• The FT232RL has a low 15mA operating supply current and a very low USB suspend current of approximately 70μA. (Note that during suspend mode, the current drawn by application should not exceed 2.5mA to remain USB compliant)
• Compatible with windows, linux and Mac OS. Windows8 / 10, Mac OS does not need to install the driver manually When your laptop/PC is connected to the Internet , plug and play.The drivers listed above are all available to download for free from FTDI website (http://www.ftdichip.com/Documents/InstallGuides.htm).
• The TTL cables are capable of operating over an extended temperature range of -40º to +85º C thus allowing them to be used in automotive or industrial applications.

1.Typical Applications · USB to Serial TTL Level Converter · Upgrading Legacy Peripherals to USB · Interface Microcontroller UART or I/O to USB · Interface FPGA / PLD to USB · Interface to FTDI VDRIVE2 or VMUSIC2 modules. · Replace MAX232 type level shifters allowing for direct connection of products to PC via USB · USB Instrumentation PC interface · USB Industrial Control 2. Driver Support · Windows 10 32,64-bit · Windows 8/8.1 32,64-bit · Windows 7 32,64-bit · Windows Vista and Vista 64-bit · Windows XP and XP 64-bit · Windows 98, 98SE, ME, 2000, Server 2003, XP, Server 2008 and server 2012 R2 · Windows XP Embedded · Windows CE 4.2, 5.0 and 6.0 · Mac OS 8/9, OS-X · Linux 2.4 and greater
