Uponor T-23 with Scala Wired 230V Sensor Room Control Thermostat 1058422

• Temperature range: +5 to +30 °C
• Operating voltage: 230 V AC, 50 Hz
• Adjustment range can be limited with insert pins under the rotary scale
• Colour: ~ RAL 9010
• Manufacturer number: 1058422

Uponor thermostat T-23 230V, wired manufacturer number: 1058422 The room thermostat T-23 with scale is an easy-to-use, wired standard 230V thermostat. The required room temperature can be set with the integrated command dial. Since this room thermostat only processes on/off values, it can be exchanged for almost all other 230V room thermostats with on/off control. A surface mounting frame is available separately. Functions: Simple on/off control (bimetal) Temperature range 5-30°C setting range can be limited with plug-in pins below the rotary scale Power supply via base unit (230V) Color: ~ RAL 9010 Protection class: IP 30 Conformity: CE Wire connection: 4 x 1.5mm² Max. cable length: 100m
