Universal Test Frame PCB Testing Jig PCBA Test Fixture Tool Bakelite Fixture Test Rack Printed Circuit Board Test Fixture (100-80-42)

• ➤1. The cover can be opened to facilitate the welding line;
• ➤2. Replace the A, B, C board for easy replacement
• ➤3. The Distance between B and C board is adjustable;The C board adapter plate can be rotated by 90°.
• ➤4. The positioning pin has insufficient elastic force, and 4 holes are reserved for convenient increase;
• ➤5. Standard fitting hole position, accessories are free to choose;

➤How To Choose The Embryo Frame: ▸The size of the circuit board is within 80*50MM, and the embryo frame of model 80-50-42 is selected; ▸Within the size of 100*80MM, select the frame of 100-80-42 type; ▸Within the size of 130*100MM, select the 130-100-42 type embryo frame; ▸Within the size of 150*130MM, select the frame of 150-130-60; ▸Within the size of 180*150MM, choose the 180-150-60 type embryo frame; ▸Within the size of 240*180MM, choose the 240-180-60 type of embryo frame; If the size is larger than 240*180MM, contact customer service and give you a private order! ➤description： ▸The test rack of each model contains the corresponding ABC board, such as FC80X50X42, which contains 80X50X42ABC board. ▸If you need to purchase ABC board separately, please contact customer service to purchase it! ▸The FC80-50-42 can be tested with a PCB board with a maximum size of 80X50MM, and a PCB board within 80X50MM can be used to select the frame, and 42MM indicates the test schedule. ▸If you need to test different PCB boards, you can process the ABC board and suggest several sets of ABC boards. ▸The material of ABC third board is: 8-10MM transparent acrylic sheet (80-50-42, 100-80-42, 130-100-42, transparent acrylic thickness is 8MM,150-130-60\180-150-60-240-180-60. 3 board transparent acrylic thickness is 10MM.) ▸The frame material is the electric wood, the express logistics is very safe.
