Universal Metal Anchor 6 mm x 32 mm Zinc Plated for Cellular Concrete Expanded Clay Block Utilised as Expansion Element Combined with Screw-in Expansion pin KMG Screw-in Hooks Pack of 10 pcs

• DROP-IN-ANCHORS - Metal anchor has ribbed design which provides easy screw tightening, and outer teeth allow for transfer of heavy loads.. Using a setting tool expand the anchor within the hole in the concrete. Drop-in anchors require a setting tool to install.
• EASY INSTALL - Bullet type anchor shell with internal thread for pre-positioned installation. When the bullet is placed in shell & hit with a setting tools it slides forward & the inside part of shell expands and takes the grip in the wall.
• ADVANTAGES - Cold region cannot use plastic wall anchor duing to it is eazy pull out . especiall good for solid soft wall. The reinforced walls of the anchor make it possible to achieve high loads while maintaining resistance to vibration.
• UNIVERSAL USE - Universal metal hammer-in anchor by Keple utilised as expansion element combined with screw-in expansion pin (screw, screw-in hook, etc.)
• DIMENSION - Hammer-in anchor KMG is made of carbon steel with protective zinc coating. Anchor diameter - 6 mm. Minimum anchoring depth - 32 mm. Pack of 10 pcs.

Expanding Hammer-in Anchor Are you looking for plugs to insert screws into your cellular concrete or expanded clay block ? Then you need universal hammer-in plugs! These universal hammer-in anchor KMG is made of carbon steel with protective zinc coating. The anchor is used as a body for screw-in elements, such as screws, screw-in hooks. Metal anchor has ribbed design which provides easy screw tightening, and outer teeth allow for transfer of heavy loads. Fixing is executed by driving the screw into the anchor which causes its expansion and creates a permanent anchorage. Types of substrates on which anchor KMG can be installed: - autoclaved aerated concrete Installation: 1. Use proper method of drilling according to a substrate type (holes in masonry substrate made of autoclaved aerated concrete blocks should be drilled using a drill without impact) 2. Diameter of drilled holes should match diameter of the anchors used 3. Drilled holes in substrates of solid materials should be deeper by min. 10mm compared to the plug anchorage depth 4. Clean the holes in solid materials of drillings with a back and forth motion of the drill at a reduced speed 5. Then insert the anchor into a drilled hole, and drive the screw until it completely penetrates the body Anchor size: Anchor diameter - 6 mm Minimum anchoring depth - 32mm Pack of 10 pcs.
