TOPXCDZ High Power UV Purple LED Chips 365nm 370nm 375nm 385nm 395nm 400nm 405nm 425nm COB Ultraviolet Lights 3W 5W 10W 20W 30W 50W 100W (395nm-400nm, 10W x 1 Pieces)

• 3W: Volt 3-3.4V 400-500mA 5W: Volt 6-7V 600-700mA 10W: Volt 9-11V 900mA 20W: Volt 30-34V 600mA 30W: Volt 30-34V 900mA 50W: Volt 30-34V 1500mA 100W: Volt 30-34V 0-34V 3000 mA
• When making the system design. To avoid intense heat generation, theoperating current should be decided after considering the ambient maximumtemperature of LED’s. The operate within the maximum current ratings.
• Ultraviolet Bulbs Lamp Chips 365nm 375nm 380nm 385nm 395nm 400nm 405nm 410nm 420nm
• 50000 Hours Life Span (Working Temperature should be less than 60℃(140℉) with a Heat Sink System)
• Constant current LED drivers are recommended for high performance COB LED chips. The LEDs must be mounted on a metal core circuit board, heat sink or thermal pad. The LED working temperature is regulated below 60°C.

3W: Volt 3-3.4V 400-500mA 5W: Volt 6-7V 600-700mA 10W: Volt 9-11V 900mA 20W: Volt 30-34V 600mA 30W: Volt 30-34V 900mA 50W: Volt 30-34V 1500mA 100W: Volt 30-34V 3000mA Constant current LED drivers are recommended for high power COB LED Chip(not include) The LEDs must be mounted on metal core PCB, heat sink or thermal pad. The LED work temperature is controlled below 60°C.
