TECSUN PL-380 FM Stereo Portable Radio MW. SW. LW. DSP with ETM PLL World Band Radio Antenna LCD Display Receiver Black.

• Easy Tung Mode function (ETM) for FM, MW, LW & SW bands
• The United States SILICON LABS si4735 digital signal processing (DSP) chip
• ATS button / Alarm set
• Key lock, Light /sleep
• 7 modes: ETM (Easy Tuning Mode), Dial manual, Auto scan tuning, Pre-setting manual scan tuning, Memory pre-setting auto scan tuning, Memory pre-setting address, direct entry tuning

Description This machine adopts the United States SILICON LABS si4734 digital signal processing (DSP) chip, the analog FM / AM radio signals to digital conversion, and the basic principles involved the use of modern software-defined radio. Processing and demodulation, which greatly improves the listening sensitivity, selectivity, signal to noise ratio, and anti-jamming. Specification Frequency Information FM :87 ~ 108 MHz (Russia 64 ~ 108 MHz, Japan 76 ~ 108 MHz, China,USA 87.5 ~ 108 MHz) MW 531-1602KHz (USA520-1710kHz)(9/10 kHz STEP) AM :522 ~ 1620 KHz (USA 520 ~ 1710 KHz) SW : 2300 ~ 21950 KHz LW : 153 ~ 513 KHz Sensitivity FM <3 ¦ÌV MW <1 mV/m SW <20 ¦ÌV LW <10mV/m Selectivity FM >60dB MW >60dB LW >60dB SW >60dB Other Information FM Stereo crosstalk : 35dB Output : 350mW Power : UM3 or AA*3, USB 5V DC Programmable memories: 550 Speaker: ¦µ50mm, 500mW/16 Ohm Earphone Jack: 3.5mm, 32 Ohm, Stereo type Package Tecsun PL-380 Stereo Receiver(batteries not included) Stereo Earphone Carrying Pouch User manual Time settings 1. Long press [TIME] button until "hour" is flashing in the display. Rotate the [TUNING] knob to adjust the correct "hour". 2. Short press [TIME] button again, rotate the [TUNING] knob to adjust "minute". 3. Press the [TIME] button again to confirm your time setting.
