5pcs SR501 HC-SR501 HCSR501 Adjust IR Motion Sensor โ€” image 1
Motion DetectorsTECNOIOTโœ“ In stock

5pcs SR501 HC-SR501 HCSR501 Adjust IR Motion Sensor

โ˜…โ˜…โ˜…โ˜…โ˜…
$24.67
Worldwide shipping
Fast tracked delivery
30-day returns
Hassle-free returns
Secure checkout
Safe & protected
Great service
Thousands of happy customers
About this item
  • ใ€Easy operation-1ใ€‘1. Sensing module for about a minute after power initialization time, during the interval to the output module 0-3 times a minute in standby mode.2. Should avoid direct lighting such as interference sources close the surface of the lens module so as to avoid the introduction of interference signal generator malfunction; use of the environment to avoid the flow of the wind, the wind sensor will also cause interference.
  • ใ€Easy operation-2ใ€‘3. Sensor module using a dual probe, the probe's window is rectangular, dual (A per B million) in the direction of the ends of long, when the body passed from left to right or right to left when the reach the dual IR time, distance difference, the greater the difference, more sensitive sensors, when the body from the front to the probe or from top to bottom or from bottom to top direction passing, dual IR not detected changes in the distance;
  • ใ€Easy operation-3ใ€‘so the sensors should be installed dual direction of the probe with human activities as much as possible parallel to the direction of maximum to ensure that the body has been passed by the dual sensor probe. To increase the sensing range of angles, the module using a circular lens, the probe also makes sense on all four sides, by the above installation requirements.VCC, trig (control side), echo (receiving end), GND.
  • ใ€Easy operation-4ใ€‘5, with induction blocking time (the default setting: 2.5S block time): sensor module, after each sensor output (high change Into a low level),can set up a blockade followed by time period, in this time period the sensor does not accept any sensor signal. This feature can have a "sensor output time" and "blocking time" the interval between the work produced can be applied to detect the interval Products .
  • ใ€Easy operation-5ใ€‘6, the working voltage range: the default voltage DC4.5V-20V. 7, micro-power consumption: static current "50 microamps, especially for battery-powered automatic control products. !!Note!!: The potentiometer clockwise to adjust the distance, sensing range increases (about 7 meters), on the contrary, sensing range decreases (about 3 meters).Delay adjustment potentiometer clockwise rotation, sensor delay longer (about 300S), the other hand, induction by the short delay (about 5S).
Product details
Brand
TECNOIOT
Manufacturer
TECNOIOT
