Tece WC Module TECElux 400 BH1120mm Height Adjustable, with Odour 9600400

• Package weight :45.9pounds
• item package dimensions (LxWxH) :113.5x53x22.6 centimeters
• Model Number:9600400
• Item package quantity: 1.0

TECElux washbasin module for spout drywall element for attachment to TECEprofil section pipes or for installation in metal or wooden studs and as a prewall or corner module. For TECElux actuating glass plate sen-Touch and toilet glass plate, subsequently 8 cm manually height-adjustable, including odor extraction Ceramic-Air pre-assembled unit, consisting of: tece-up cistern: safety tank made of impact-resistant plastic cistern completely pre-assembled and sealed angle valve and cistern connection pre-assembled Cistern connection with 1/2 inch external thread, 10 litre tank volume, 6 litres of preset standard flush volume, 9/7.5/4.5 litre flush volume optimally adjustable at any time, 3 litres of partial flush volume with dual-flush technology. Residual volume can be used for immediate cleaning flushing. condensation insulated according to DIN EN 14055 fitting group 1 to DIN 4109 low-noise hydraulic filling valve Including insertion shaft for cleaning rods. Allows cleaning tablets to be added to the cistern for a fresh toilet flush. Module: self-supporting mounting frame with powder-coated surface, depth-adjustable receptacle for upper actuating glass plate and lower toilet glass plate, also manually height-adjustable two adjustable footrests for a floor structure of 0-200 mm, two retaining bolts and nuts M 12, mounting for toilet ceramics with a distance of 180 mm. Flexible toilet drain bend DN 90, connection piece material PE-HD (weldable), including adapter DN 90/100 made of PP toilet connection set DN 90, including safety plug, large shell protection suitable for wall structures up to 45 mm. Dimensions (H x W x D): 1120 x 500 x 160 mm, low-noise odour extraction ceramic-Air with Long-term filter cartridge.
