Tbs Octo Freeview Cable Dvb-T2/C2/T/C/Isdb-T Hd Pci Express Card 8 Tuners Red

• receive eight channels simultaneously
• High-definition video in real time and switched time record
• High sensitivity DVB-T2-octa-tuners for the best digital TV reception
• Windows BDA driver and Linux driver
• Windows BDA driver and Linux Driver ready

The TBS-6209 is a DVB-T2 / C2 / T / C / ISDB-T octa-tuner card with PCIe interface and can be used to 8 different channels to see 8 different frequencies and take. They simultaneously supports the DVB-T2 and DVB-C2 standard. She works as a digital video recorder for recording digital terrestrial TV and supports all HD resolutions. The TBS-6209 is suitable for professional use on an industrial scale. If you have a few PCIe slots in your server, allows you to TBS-6209 to receive more channels than an ordinary dual- or quad-tuner card. This card is suitable systems broadcasting for IPTV streaming and. Technical Specification DVB-T2 and T2-Lite: Channels: VHF band, UHF band Bandwidth: 1st 7, 5, 6, 7, 8 MHz FEC: QPSK, 16QAM, 256QAM FFT mode: 1K, 2K, 4K, 8K, 16K, 32K, Code rate: 1/2, 2/3, 3/4, 5/6 , 7/8 DVB-C2: COFDM demodulator (16_QAM to 4096_QAM) FEC (LDPC / BCH) decoder bandwidth: 6MHz, 7MHz, 8MHz DVB-C: QAM demodulator FEC decoder to 1. 7 2MSymbol / s ISDB-T: COFDM and FEC decoding Supports 3 layer decoding TMCC decoding Supports differential demodulation AC1 and AC2 decoding Input / Power: 14W 12V connections and technical data / Max. Dimensions of the card (B x T): 104th 5mm 150mm Weight: approx. 0. 3 kg Minimum System requirements Operating system (32-bit and 64-bit): Windows XP, Vista, Windows7, Windows8. x, Windows10, Linux Free PCIe slot (x1, x4, x8 or x16) digital TV signal (DVB-T2 / C2 / T / C) Package 1 x TBS-6209 1 x PCIe power cable 1 x F Adapter 1 x driver, Quick installation guide and software (via download)
