TBS 6281-SE Dual Terrestrial HD Low-profile PCIe TV Tuner Card (DVB-T2)

• A twin tuner TV card with PCI-E Interface, it supports to watch and record two different channels from two different frequencies at the same time supports DVB-T and DVB-T2
• Have low profile; High Definition Video. This DVB-T2 PC TV card is ready with Windows BDA driver and Linux driver.
• Record the video in real time, it also allows you to pause a live broadcast and continue from where you left with the time-shifting function
• For reception of digital TV, it is ideal for viewing the United Kingdom TNT – Channel SD and HD channels on your PC.
• System Requirement: Windows XP/Vista/8.7.10, Linux; available PCI Express x1, x4, x8 or x16

tbs6281se, successor of TBS6280, can be used as a digital video recorder for recording digital terrestrial TV programs to support HDTV.. This DVB-T2 PC TV card is ready with windows BDA driver and Linux driver. N.B Make sure you can receive the Digital Terrestrial Television (DVB-T, dvb- T2, DTT) service in your area please. TBS6281 requires you to use a roof to enable and enjoy reliable Digital Television reception aerial high gain in the United Kingdom. TBS 6281 has one RF IN port, and one LOOP OUT port. The RF IN port is for connecting to antenna, while LOOP OUT port is intended to convey a singal to another receiver DVB-T2. Specifications Reception: VHF band and UHF channels Channel Bandwidth: 6, 7, 8 MHz DVB-T/T2 Type of Modulation: QPSK, 16QAM, 64QAM, 256QAM FFT Mode: 1 K, 2 K, 4 K, 8 K, 16 K, 32 K Code rate: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 7/8 Maximum internet: 1/4, 1/8, 1/16, 1/32, 1/64, 1/128, 19/128, 19/256 Intermediate Frequency & # xff1 a; If: If bas Centre if Frequency: 3 ~ 5 MHz Note: Default 4MHZ Input rf-impédance 75 & # x3 a9; (iec-din female) rf-impédance output 75 & # x3 a9; (iec-din Male) DVB-C Fully compatible with B/C Specifications ITU J83 A DVB-C and receiving frequency: 47 ~ 862 MHz Tuning Range Input Level: -65 ~ -10dBm qam-32, 16QAM, 64QAM, 128QAM and support 256QAM Symbol rate: 0,87 to 9mbaud Package including: 1 x tbs6281se DVB-T2/T/C TV tuner card PCIe 1 x Profile Low 1 x Female Connector
