T.I.P. Maxima 180 SX 30121 Stainless Steel Submersible Waste Water Pump

• Strong submersible pump with a high output, universal use. High quality stainless steel pump housing, for transporting clear and dirty water up to 25 mm Grit size.
• Motor output is 500 watts of maximum Föder Height of 7 m (Max. 0.7 bar)
• For drainage Keller in case of unattended, sewage Sewer, draining Garden Ponds and cisterns. Maintenance-free Capacitor Motor with thermal overload protection pump housing made from stainless steel with a Selbstreinigendes Vortex impeller Noryl.
• Maximum Immersion Depth is 9 m
• Maximum Amount of Föder is 10,500 L/H

Tip Maxima 180 SX Max dirty water submersible pump. Fö 10.500l/H Universal entry-level model in the high quality and extremely robust Series Maxima. High quality pump housing made of stainless steel. With Vortex impeller system to minimise blockages of pump. To be used to pump clean water or dirty water with dirt up to 25 mm grain size. Particularly suited to inserts, a robust and Resistenteres Material is needed, such as for drainage for ponds, building and dirty water drainage pits, for waste water Sewerage system or for emergency in case of flooding. Technical details Motor: 500 Watt Max. Maximum flow rate: 10,500 L/H Max. Delivery height 7 m Max. Grain size: 25 mm Min) and A4-80 Stainless Steel Screw Material. Suction Level: 37 mm Pump housing: Stainless Steel Max. Temp. Liquid: 35º C Max. Immersion Depth: 5 m Pressure connection: AG 41.91 mm (1 1/4 inch) Cable Length: 10 m Cable Type: H05RN-F Package Dimensions (cm): 35 x 22 x 19 Weight (Gross): 4.9kg Item number: 30121 Output and pump head Pump head Maximum flow rate 6 m 32 L/min. 3/4 M³/H 5 m 65 L/min 3.9 m³/h 4 m 77 l/min 4.6 m³/h 3 M : 100 L/min 6.0 m³/h 2.5 m 112 L/min 6.7 m³/h 2 m 123 litres/min 7.4 m³/h 1.5 m 135 L/min 8.1 M³/H 1 m 147 L/min 8.8 m³/h 0.5 m 158 L/min 9.5 m³/h Table: performance Maxima 180 SX The output of a pump is mainly dependent on the pump head. In addition to standing table gives you the ability to perform at optimum level of dirty water submersible pump Maxima 180 SX at varying heights. Example: Promotes water from 2 meters depth, in this pump with a flow rate of 123 liters per minute or 7.4 Kubikmetern per hour to rechnen. is Free All information about Output and pump head have been reproduced in M, Unreduziertem Spout and weight.
