T.I.P. 30156 Zisternenpumpe EJ 6 Plus Complete with hose and floating removal

• The pump has a closed with Volledelstahlgehäuse Radiallaufrädern from Noryl. specially designed for use in Regenwassersammelsystemen designed
• The high-quality floating suction set is always the only sauberste water drawn from the ground and not applicable
• Maintenance-free Kondensatormotor with thermal overload protection, water-cooled, suitable for long-term operation
• Ballschwimmer (floating), Collection, Ablassseil Suction Set
• Motor, multi-stage rotodynamic 1.400W FH / max, pressure 0.60 yrd (.55 m)/FM max.6.000 bar 5.5 l / h, stainless steel case, Korngrösse max Inch 0.01 (.2 mm), maximum immersion depth 21.87 yrd (20 m) Cable 21.87 yrd (20 m), temperature, max. 35°C; 1.56 inch pressure/(39.59 mm) IG. suction connection 1 1 / 4 ") Inch / IG. 1.22 (30.93 mm) (1")

The T.I.P. EJ 6 PLUS is a high quality, multi-stage cistern pump with excellent performance data. It has a full steel housing with closed radial wheels made of Noryl and with the wide base is specially designed for use in rainwater collection systems. Thanks to the water-cooled and maintenance-free condenser motor with thermal overload protection, the pump is ideal for continuous operation. Multiple pumps can be connected to increase the performance by using the suction connector with 30.93 mm (1 inch IG) thread. In combination with a floating intake, an automation computer and if necessary. A pressure kettle turns the EJ 6 Plus into a high-quality and extremely quiet alternative to water supply in the home and garden. Thanks to the high-quality floating 1 inch suction set, the suction of dirt particles from the floor is prevented. Technical data: Motor: 1,400 watts Max. Delivery height: 55 m Max. Flow rate: 6,000 l/h Max. Pressure: 5.5 bar. Max. Grain size: 2 mm. Pump housing: stainless steel. Max. Temp. Liquid: 35 oC Max. Immersion depth: 20 m Fountain diameter: min. : 36 cm Pressure connection: IG 30.93 mm (1 inch). Connection cable: 20 m Cable type: H07RN-F; Number of sprinklers max. : 6 Box contents: Includes drain rope Includes floating water removal (ball float and suction hose). Flow height / flow rate 45 m - 1,700 l/h 40 m - 2,600 l/h 30 m - 3,950 l/h 20 m - 4800 l/h 15 m - 5,100 l/h 10 m - 5,450 l/h 5 m - 5,700 l/h The flow rate of a pump depends mainly on the delivery height. The above table shows the performance of the EJ 6 Plus cistern pump in various
