SPARKHOBBY UBEC 3A 2-6S Lipo / 5A 2-8S Lipo Voltage regulation Power Supply Module Antijamming For Hobbywing BEC Suitable for RC Fixed Wing Drones (UBEC 5A -V2-Air 1PC)

• UBEC 3A:This UBEC is an external switching mode DC-DC regulator; it draws DC voltage from 2-6S LiPo battery, drops it to a voltage level that is suitable for your receivers and other electronic devices, and keeps providing the stable current output of 3Amp. It's compatible with different brands of ESCs.
• UBEC 5A:The UBEC uses an efficient DC-DC regulator chip with a conversion efficiency of more than 90%. UBEC output voltage is adjustable in three stages (5.0/6.0/7.4 V) with a continuous current of 5A and a maximum of 15A. The voltage specifications allow the use for a wide range of servos and electrical equipments. The UBEC is equipped with overcurrent protection, output short-circuit protection, overheat protection.

Item: UBEC 3A / 5A for Hobbywing UBEC UBEC 3A: This UBEC is an external switching mode DC-DC regulator; it draws DC voltage from 2-6S LiPo battery, drops it to a voltage level that is suitable for your receivers and other electronic devices, and keeps providing the stable current output of 3Amp. It's compatible with different brands of ESCs. Parameters: Output Voltage/Current: 5V@3A / 6V@3A (adjust via jumper cap) Input Voltage: 5.5-26V (2-6S LiPo/5-18 Cells NiMH/NiCa) Size: 43x17x7mm (LxWxH) Weight: 11g Ripple: less than 50mVp-p (@2A/12V input) UBEC 5A: The UBEC uses an efficient DC-DC regulator chip with a conversion efficiency of more than 90%. UBEC output voltage is adjustable in three stages (5.0/6.0/7.4 V) with a continuous current of 5A and a maximum of 15A. The voltage specifications allow the use for a wide range of servos and electrical equipments. The UBEC is equipped with overcurrent protection, output short-circuit protection, overheat protection. Parameters: Model:UBEC 5A Input voltage:2-8S Lipo Output voltage:5.0 / 6.0 / 7.4 V (3 options adjustable) Output current:Continuous 5A,Instantaneous 15A Measurement:50*17*10mm Weight :21g Package Included: UBEC 3A x 1 or UBEC 5A x 1 0r UBEC 3A x 4 or UBEC 5A x 4
