Sourcingmap AC 20A/125V 22A/250V DPST 4 Pins 2 Positions I/O On/Off Boat Rocker Switch w Backlit Red Light

• 【Wide Application】Universal for Electromagnetic furnace, Water dispenser, buses, boats, marine, trailers，kitchen appliance etc.
• 【DIY As You Like】4 Terminal,Voltage & Current : AC 125V/20A 250V/22A gentle lighting, longer life for use.
• 【Product Basic Parameters】Overall Size:32 x 25 x 38mm (L*W*H) Mounting Size:31 x 22mm (L*W)
• 【Attention】Select the appropriate soldering iron to speed up the soldering. It is recommended to use 20W soldering iron to complete the soldering within 3 seconds. The flux must be in proper amount. When soldering, try to turn the switch pin down.
• 【Parcel contains】1 x Rocker Switch . Easy to install and durable.With our strict quality control system, we test each item and ensure in good condition before we ship.

Specification: Product Name:Rocker SwitchPole and Throw:DPSTTerminal Quantity:4Position:On-OffLamp Color:RedRated Voltage:AC 20A/125V 22A/250V(for resistive load only)Overall Size:32 x 25 x 38mm (L*W*H)Mounting Size:31 x 22mm (L*W)Color:Black,RedMaterial:Plastic, MetalPackage Content:1 x Rocker Switch AC 250V Current rerating for different loadsInductive Load: 7.7ALamp Load: 3.96AMotor Load: 4.4ACapactive Load: 3.96A AC125V Current rerating for different loadsInductive Load: 7ALamp Load: 3.6AMotor Load: 4ACapactive Load: 3.6A Very Important Notice:Ratings on the switch label are only for Purely Resistive AC load, for other types of loads please refer to the ratings above.DC load Current ratings are much lower than AC load,if you need to use this switch with more than 0.5A DC load,contact us for compatibility at first.
