sourcingmap AC 1A 85L1 Analog Panel Current Ampere Meter Ammeter Gauge 0-1A

• Country of Manufacture: CHINA; Brand: DMiotech; Material: Analog Ammeter
• Net Weight: 112g; Package Content: 1 x Analog Ammeter
• Model: 85L1; Measuring Current Range: AC 0-1A
• Accuracy: Class 2.5; Thread Dia: 3mm/0.12", 4mm/0.16"
• Panel Size: 63 x 55 x 10mm/2.5" x 2.2" x 0.4"(L*W*T); Total Height(Screw not Included): 48mm/ 1.9"

Model: 85L1Measures current range: AC 0-1A Accuracy: Class 2.5Withstand voltage: 2000V for 1 minuteDamping response time: Less Than 4s.Operating temperature: -10C to + 55CClear and easy to read scale.Do not require current shuntThis meter does not need current shunt, can be connected directly.Package: 1 x Meter, some mounting screws.
