OSRAM Electronic Control Gears (ECG), HALOTRONIC-Compact HTM, HTN, ECG, HTM 150/230-240

• Strain relief suitable for different cable types (HTM)
• Suitable for space-critical installation thanks to compact functional design
• Extremely compact transformer for highly space-critical installation conditions (HTN)
• Protective operation throughout the entire partial-load range for long lamp life
• Product family features: Line frequency: 50…60 Hz

Product family benefits: Very low power loss thanks to high efficacy. Strain relief suitable for different cable types (HTM). Suitable for space-critical installation thanks to compact functional design. Extremely compact transformer for highly space-critical installation conditions (HTN). Protective operation throughout the entire partial-load range for long lamp life. Product family features: Line frequency: 5060 Hz. RI suppression: to EN 55015 (A1: 2007)/CISPR 15, EN 55022. Line harmonics according to EN 61000-3-2. Immunity according to EN 61547. Safety: to EN 61347. Short-circuit protection, overload protection, overtemperature protection: electronically reversible. Electrical isolation between the primary side and the secondary side. Energy efficiency: 91 % (according to ErP regulation 2012/1194/EC). Dimmable on the leading edge (without HTN) and trailing edge. Areas of application: Effect and accent lighting. Living rooms. Object lighting. Conference rooms. Restaurants. Recessed and surface-mounted furniture luminaires. Shop lighting. Event rooms.
