SENSTREE G3/4" Water Flow Sensor, Food-Grade Hall Effect Sensor Flow Meter Flowmeter Counter 1-60L/min - Arduino, Raspberry Pi, and Reverse Osmosis Filter Compatible

• ☺Work for Arduino, Raspberry Pi, and Reverse Osmosis Filter. Small size, waterproof, easy to install, heat resistance, pressure resistance, cold resistance.
• ☺Material: food grade, all materials are in line with ROHS testing standards, can be used for potable water.
• ☺Cable length: 15cm. Flow range:1-60L/min, working voltage range:DC 5-18 V, allow compression:Water pressure 1.75 Mpa below.
• ☺Hall effect sensor. Connect to G3/4 inch BSPT male thread, if used for NPT, need thread seal tape. Output waveform: square wave,output pulse signal.
• ☺Wide application: It is mainly used in water heater, coffee machine, water purifier, drinking fountain, beverage machine, campus smart card equipment, etc.

Specifications: Frequency: F=5.5 * Q (L / Min), error: ± 2%, current can not exceed 10mA, 330 pulses/liter. F=onstant * units of flow (L / min) * time (seconds). Flow range:1-60L/min Maximum current:10 mA(DC 5V) Working voltage range:DC 5-18 V Load capacity:≤10 mA(DC 5V) Operating Temp: ≤80℃ Operating humidity: 35％ - 90%RH Allow compression:Water pressure 1.75 Mpa below Insulation resistance: >100M OHM Storage Temperature:-25℃～80℃ Storage humidity:25%～95%RH Output Waveform:Square Wave,output pulse singal. Cable length:15cm. Package include: Flowmeter x 1
