SDA25 Pneumatic Air Cylinder Double Action 25mm Bore x 30mm Stroke Aluminum Construction M5 Thread 0.1-1MPa Working Pressure Anti-Collision Pad

• The front cover adopts self-lubricating bearing guide, good lubrication and guiding performance, and easy to install.
• Double seal structure: The piston seal adopts a special type of double seal structure, which will not cause leakage, is compact, and has oil storage function.
• Pneumatic Air Cylinder: Model: SDA25 * 30; Inner hole: 25mm / 0.98inch; Stroke: 30mm / 1.18in; Working pressure: 0.1~1Mpa; Guaranteed pressure resistance: 1.5MPa (215Psi); Opening diameter: M5 * 0.8; Buffer: anti-collision pad
• After-sales service: Pneumatic Air Cylinder has passed quality inspection before leaving the factory, and can provide you with high-quality quality assurance and after-sales service, so you can use it with confidence.
• High-quality aluminum round tube cylinder: The cylinder is made of high-quality aluminum round tube cylinder. The front and rear covers are screwed to the cylinder tube, which has a long service life.

Specifications: Model: SDA25 x 30. Bore: 25 mm/0.98 inches. Stroke: 30 mm/1.18 inches Main material: aluminium. Working environment: air Working pressure: 0.1~1Mpa Guaranteed Proof Pressure: 1.5MPa (215Psi) Hole diameter: M5 x 0.8. Action: double effect Buffer: anti-collision buffer Temperature: -15°C to 80°C (4°F to 176°F) Size: 5.5 x 4 x 4 cm/2.17 x 1.57 x 1.57 inches. Weight: 171 g Package includes: 1 x air cylinder.
