Schneider Electric A9F06206 Circuit Breaker iC60H 2P 6A B Characteristics 6 Amp B

• Reliable circuit breaker from Schneider Electric with two poles and a rated current of 6 amps.
• Provides protection against overload and short circuit in two-phase circuits.
• The circuit breaker has a B characteristic that allows quick shutdown in case of short circuits.
• Suitable for use in residential and commercial buildings to protect electrical wiring and equipment from damage.
• Meets international safety standards and provides a compact and reliable solution for line protection.

Circuit breaker Acti 9 iC60H, 10kA (IEC/EN 60898-1), 15kA (IEC/EN 60947-2). 2-pin, rated current 6A, B characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (Ui) 500V AC. Double terminal for cable and pin comb bar on the top and bottom of the device. Jump circuit for low-wear switching of the contacts. Travelling insulation cover. Actuation of the DIN rail mounting element on the front of the device for tool-free installation and easy access for the user. With mechanical front error message indicator (VisiTrip) to indicate overload or short circuit triggers. Safe contact indicator (VisiSafe) of the circuit breaker, when the indicator is green, the safety of voltage clearance on the outlet side. Trigger unit technology - thermomagnetic Can be combined with the Acti 9 iID series FI circuit breakers, as well as the FI Block Vigi iC60. Additional stackable auxiliary modules (optional)- display of switching position, fault triggering, working current trigger, undervoltage trigger, surge trigger. Colour: RAL 9003. The iC60H circuit breaker meets the following standards - IEC/EN 60898-1 and IEC/EN 60947-2. Furthermore, this series is VDE certified.
