Sandvik Coromant TLRP-3062R 1125 Top Lok Insert for Profiling

• Benefits of this product family: Multiply operations with the same holder by just changing insert
• Double-ended inserts provide high edge security
• Interchangeable with similar clamping systems by changing the top clamp and screw

Part of the Top Lok product family. ​The flexible Top-Lok clamping system locks the insert against both the back and side of the pocket, while at the same time pulls the insert down into the pocket. This provides for clamping integrity axially and radially. PRODUCT SPECIFICATION: Grade: 1125 ; ISO Cutting Tool Material: HC ; Coating Process Type: PVD ; Coating Type: TiCr,AlN+ TiAlN ; Substrate Type: WC ; AN, Clearance Angle Major: 10 deg ; APMX, Depth Of Cut Maximum: 3.81 mm ; APMX, Depth Of Cut Maximum: 0.15 inch ; BAMS, Machine Side Body Angle: 0 deg ; CDX, Cutting Depth Maximum: 3.81 mm ; CDX, Cutting Depth Maximum: 0.15 inch ; CUTINT_SIZESHAPE, Insert Size And Shape: Top-Lok -style 3R ; CW, Cutting Width: 3.1496 mm ; CW, Cutting Width: 0.124016 inch ; CWTOLL, Cutting Width Lower Tolerance: -0.0254 mm ; CWTOLL, Cutting Width Lower Tolerance: -0.000984 inch ; CWTOLU, Cutting Width Upper Tolerance: 0.0254 mm ; CWTOLU, Cutting Width Upper Tolerance: 0.000984 inch ; HAND, Hand: R ; RE, Corner Radius: 1.5748 mm ; RE, Corner Radius: 0.062008 inch ; WT, Weight Of Item: 0.0089 kg ; WT, Weight Of Item: 0.0196 lbs ;
