Sandvik Coromant N151.2-A125-30-4P235 T-Max Q-Cut insert for profiling (Pack of 10)

• Benefits of this product family: Excellent surface finish due to wiper technology
• Proven, versatile system
• Large variety of widths

Part of the T-Max Q-Cut product family. T-Max Q-cut is a universal single edge system for parting off, grooving and internal face grooving, suitable for parting off large components and deep grooving applications. PRODUCT SPECIFICATION: Material classification (TMC1ISO): P (ISO P Steel); Application: Light ; Condition: Difficult ; Grade: 235 ; ISO Cutting Tool Material: HC ; Coating Process Type: CVD ; Coating Type: Ti (CN) +TiN ; Substrate Type: WC ; AN, Clearance Angle Major: 7 deg ; APMX, Depth Of Cut Maximum: 1.27 mm ; APMX, Depth Of Cut Maximum: 0.05 inch ; BAMS, Machine Side Body Angle: 0 deg ; CBMD, Chip Breaker Manufacturer'S Designation: 4P ; CTPT, Operation Type: Finishing ; CUTINT_SIZESHAPE, Insert Size And Shape: Q-Cut 151.2 -size 30 ; CW, Cutting Width: 3.175 mm ; CW, Cutting Width: 0.125 inch ; CWTOLL, Cutting Width Lower Tolerance: -0.02032 mm ; CWTOLL, Cutting Width Lower Tolerance: -0.000787 inch ; CWTOLU, Cutting Width Upper Tolerance: 0.02032 mm ; CWTOLU, Cutting Width Upper Tolerance: 0.000787 inch ; HAND, Hand: N ; RE, Corner Radius: 1.5875 mm ; RE, Corner Radius: 0.06248 inch ; RETOLL, Corner Radius Lower Tolerance: -0.02 mm ; RETOLL, Corner Radius Lower Tolerance: -0.000787 inch ; RETOLU, Corner Radius Upper Tolerance: 0.02 mm ; RETOLU, Corner Radius Upper Tolerance: 0.000787 inch ; WT, Weight Of Item: 0.0017 kg ; WT, Weight Of Item: 0.0037 lbs ;
