Sandvik Coromant C8-PCLNR-55080-12HP T-Max P Cutting Unit for Turning

• Benefits of this product family : Dedicated grades and geometries for all applications and materials
• Productive solution with wiper and Xcel technologies
• Tools featuring high precision coolant for excellent chip breaking
• Reliable and secure machining, even in roughing applications

Product Description Part of the T-Max P product family. T-Max P is your first choice for general turning, stretching from small components to heavy machining. The inserts fit into all Sandvik Coromant high performance holding systems and can be used in a variety of applications in all materials. Geometries specifically designed for high pressure coolant are available for steel, stainless steel and HRSA materials. PRODUCT SPECIFICATION: ADINTMS, Adaptive Interface Machine Direction: Coromant Capto (bolt and segment clamping) -size C8 ; BAMS, Machine Side Body Angle: 0 deg ; BAWS, Workpiece Side Body Angle: 0 deg ; BMC, Body Material Code: Steel ; CNSC, Coolant Entry Style Code: 3: axial concentric and radial entry ; CP, Coolant Pressure: 150 bar ; CP, Coolant Pressure: 2175.57 lbf/in2 ; CUTINT_MASTER, Part 2 Of Cutting Item Interface Identifiers: CNMG 120408 ; CXSC, Coolant Exit Style Code: 8: decentral focused exit with nozzles ; DCON, Connection Diameter: 80 mm ; DCON, Connection Diameter: 3.14961 inch ; DMIN1, Minimum Bore Diameter: 110 mm ; DMIN1, Minimum Bore Diameter: 4.33071 inch ; DMIN2, Minimum Bore Diameter: 250 mm ; DMIN2, Minimum Bore Diameter: 9.84252 inch ; DPC, Damping Property: 0 ; GAMO, Orthogonal Rake Angle: -6 deg ; HAND, Hand: R ; HF, Functional Height: 0 mm ; HF, Functional Height: 0 inch ; KAPR, Tool Cutting Edge Angle: 95 deg ; LAMS, Inclination Angle: -6 deg ; LF, Functional Length: 80 mm ; LF, Functional Length: 3.14961 inch ; MIIDM, Master Insert Identification: CNMG 12 04 08 ; OHX, Maximum Overhang: 80 mm ; OHX, Maximum Overhang: 3.14961 inch ; PSIR, Tool Lead Angle: -5 deg ; RMPX, Maximum Ramping Angle: 0 deg ; TQ, Torque: 5.0 Nm ; TQ, Torque: 3.68781 ft lbs ; WF, Functional Width: 55 mm ; WF, Functional Width: 2.16535 inch ; WT, Weight Of Item: 2.67 kg ; WT, Weight Of Item: 5.874 lbs ; Box Contains C8-PCLNR-55080-12HP + incl. in box: 174.3-841M, Lever, (pcs. = 1, incl.); 174.3-821, Screw, (pcs. = 1, incl.); 171.31-850M, Shim, (pcs. = 1, incl.); 174.3-861, Shim pin, (pcs. = 1, incl.); 5691 026-03, Nozzle, (pcs. = 3, incl.); 174.1-864, Key, (pcs. = 1, incl.);
