SALUTUYA Water Tower Pool Water Level Control Relay,GRL8-01 Liquid Level Control Relay,10A AC/DC 24V-240V,DIN Rail Mount,Liquid Level Monitoring

Specification: Model: GRL8-01 Function: 2 level control mode Power terminal: A1-A2 Rated power supply voltage: AC/DC 24-240V(50-60Hz) Power consumption: Max. 2VA Sensitivity adjustment range: 5-100kΩ Supply voltage tolerance: -15%; +10% Voltage in electrodes: Max. AC 5V Current in electrodes: Max. 0.1mA Response time: Max. 400ms Electrode cable allows distributed capacitance (maximum): 800nF-100nF Electrode cable length: ≤100m Setting accuracy: 10% Output contact parameters: 1 x SPDT, 10A/AC1, 250VAC/24VDC Minimum switching power: 500mW Power indicator: Green LED Output indication: Red LED Mechanical life: 1x107 Electrical life(resistive load): 1x106 Reset time: Max 200ms Working temperature: -20℃~55℃ Mounting method: 35mm DIN rail Mounting altitude: ≤2000m Wiring capability: 1x2.5mm2or 2x1.5mm2 Dimensions: 90*18*64mm / 3.54*0.71*2.52in Weight: Approx. 82g/2.9oz PackageList: 1 * Liquid Level Control Relay Note: 1. Due to the difference between monitors and light effects, the pictures may not reflect the actual color of the item. 2. Please allow slight error due to manual measurement. Thanks for your understanding.
