ROTOR Unisex – Adult ALDHU Axle Road Standard for 43.5 mm Chain Line Crank Arms, Black, 30 mm

• 30 mm rotor axes for the modular aldhu/ vegast crank systems
• Chain line: 43, 5 mm (rim brake) / 153 mm (disc brake).
• Weight of the axle: 96 g (rim brake) / 99 g (disc brake).

30mm ROTOR axles for the modular ALDHU/ VEGAST crank systems. No. 1: ROTOR 30mm standard axle 148mm for the modular ALDHU/ VEGAST crank systems. Q factor: 148 mm (sweeping brake) chain line: 43, 5 mm (rim brake) colour: anthracite/matt no. 2 rotor 30 mm roadoffset axle 152 mm for the modular ALDHU/ VEGAST crank systems. Q factor: 152 mm (disc brake) chain line: 46 mm (disc brake) colour: anthracite/matt no. 3 ROTOR 30 mm track axle 140 mm for the modular ALDHU/ VEGAST crank systems. Attention only with 144x5 Track Spider! Q factor: 140 mm chain line: 43 mm colour: anthracite/matt. Due to the three axle lengths: No. 1: 148 mm (standard road), No. 2: 152 mm, (road offset) and No. 3: 140 mm (track), the modular ROTOR cranks can be used for a wide range of applications Track/Fixie, Road, Tria TT, Gravel CX. In addition, they fit into almost any frame. With the appropriate 30mm ROTOR bearings and the corresponding spacers, the modular ROTOR crank systems can be mounted in almost any frame.
